The DPS+ features:
Differential Pressure Switch (DPS)
The DPS+ offers a unique solid state Differential Pressure Switch (DPS) that replaces the simple electro- mechanical device that operates on the basic principles of levers and opposing forces. The state of the art solid state design offers greater accuracy reliability and serviceability.
Differential Pressure Transducer (DPT)
The DPS+ senses the pressure difference between the two ports and produces analogue output signal proportional to the range selected.
Pressure Switch (PS)
The DPS+ offers two pressue switches. The set-point and hysteresis for the switch can be modified along the operating range of the device. The switches output can be in the form of dry contact or FET output.
Pressure Transducer (PT)
The DPS+ Converts pressure into an analog electrical signal for the two pressure ports. The analogue output signal is proportional to the pressure range setup in the application.
Filter Wash Controller / State machine
The DPS+ device offers an integrated solution for filter washing application, using the device two discreet outputs. The filter wash sequence can be set from the application, using its unique State Machine approach.
Data Logger
The DPS+ device has an internal data logger that can record the device status periodicly and based on the device operation. The data can be later downloaded and analysed.
Smart Conectivity
The DPS+ is designed to offer a vast range of connectivity options. It can be connected using RS232, RS485 or GSM. The DPS+ is designed to operate either as stand alone device in the field or as part of a complex industial controlll system.
Mobile Ready
The DPS+ is a very flexible device with many features and options. To change the device settings or view the device readings, we choose to communicate with smart phone using Bluethooth 4 standard.
The DPS+ can come with part or all features based on customer requirments.
DPS+ features
DPS+ leading edge technology monitors flow and measures pressure differences by recording “high” (pre-flow constraint) and ‘low” (post-flow constraint) pressures.
It analyses the data using its own microprocessor. When pressure difference reaches the pre-set value, it activates the built-in switch and sends an electric signal. An advanced transducer version of DPS+ transmits an analogue signal in response to high, low or differential pressures.
- Solid state technology
- 36 months guarantee
- Wide adjustable range
- Compact size
- Bluetooth ,RS485 & RS232
- Data logger
- Battery or 12-24 VDC
- Programmable
- Weather proof
- Led status indicator
